Agitated Nutsche Filter Dryer ANFD Manufacturer

We have specialized in providing industrial proces equipment for fine chemicals, pesticides, new energy,new materials, and pharmaceutical industries for more than 48 years.

ANFD Equipment Overview

ANFD called agitated nutsche filter dryer is a multifunctional filter drying equipment widely used in pharmaceutical, chemical, agrochemical, and food industries. It can complete the process steps of filtration and drying at the same time, replacing traditional vacuum filters, pressure filters, double cone dryers, drying boxes, and other equipment. The main advantage of ANFD is that it integrates multiple process steps and can be completed with the same equipment. It has a stirring function to improve filtration efficiency and solid separation effect. There is a filter and a rotating scraper inside the equipment to separate solid particles and liquids. In addition, ANFD also has a washing function, which can clean solid particles by injecting detergent into the equipment. Finally, ANFD implements a drying operation by heating the material inside the device to dehydrate it.

ANFD can be manufactured using a variety of materials, such as SS304, SS316L, titanium alloy, Hastelloy and PTFE lining, etc., to adapt to different process requirements and media characteristics. It also enables continuous operation without the need for air, making it ideal for the production of sterile and toxic products. Agitated nutsche filter dryer provides efficient, flexible and safe process solutions by integrating filtration, washing and drying functions, making it one of the most ideal equipment in the field of filtration and drying.

ANFD Working Process

The Agitated Suction Filter Dryer (ANFD) is a multifunctional device that combines filtration, washing, drying, and solids discharge in one unit. The work process involves the following stages.

Filter stage

The separation of filter cake and mother liquid. The thickness of filter cake can reach 500 mm

In the filter stage of ANFD, the material to be filtered is introduced into the equipment. The liquid component passes through the filter medium, such as a filter cloth or porous plate, while the solid particles are retained. This process effectively separates the solid and liquid components, allowing for further processing or disposal of the filtrate.

ANFD - Washing stage

Further purification of filter cake, rinse and dehydration of mother liquid remained. Mix the lotion and the filter cake via up and down of agitator by layers to make the filter cake slurry finally, then the filter cake can get the full wash.

Drying stage

Dehydrating and drying the filter cake. Agitator will scrape filter cake loose by layers while the sidewall; the bottom of filter plate and agitator will heat the filter cake at the same time. Moreover, The vacuum inside the equipment will accelerate the evaporating speed; the entered hot nitrogen will take away the damp and accelerate the speed of desiccation.

Discharging section

The dried materials are automatically discharged from the side discharging vent under the reverse rotation by the S type mixing blade and enter into packaging directly.

Advantages of Zhanghua's ANFD Equipment

Zhanghua's ANFD (Agitated Nutsche Filter Dryer) equipment excels in versatile applications, ensuring efficient solid-liquid separation and continuous processing. It minimizes labor intensity, complies with GMP standards, and offers customization options, all while maintaining reliability and durability. This makes it a preferred choice across diverse industries.

Multifunctional

ANFD combines filtering, washing, and drying functions in a single unit, streamlining the process and reducing the need for multiple pieces of equipment.

Continuous Operation

ANFD enables continuous processing, enhancing productivity, reducing downtime, and meeting "GMP" requirements by minimizing labor intensity and preventing product contamination.

Material Flexibility

It can be manufactured using various materials such as SS304, SS316L, titanium alloys, Hastelloy, and PTFE lining to accommodate different process requirements and media characteristics.

Multifunctional

ANFD combines filtering, washing, and drying functions in a single unit, streamlining the process and reducing the need for multiple pieces of equipment.

Continuous Operation

ANFD enables continuous processing, enhancing productivity, reducing downtime, and meeting "GMP" requirements by minimizing labor intensity and preventing product contamination.

Material Flexibility

It can be manufactured using various materials such as SS304, SS316L, titanium alloys, Hastelloy, and PTFE lining to accommodate different process requirements and media characteristics.

Product Specification

Specification	Capacity	Filter Area	Travel Route Of The Mix Blend/MM	Electrical Motor Power/KW
φ800	0.6	0.5	250	4
φ1000	1.2	0.8	300	5.5
φ1200	1.5	1	300	5.5
φ1400	2.2	1.5	400	7.5
φ1600	3	2	400	7.5
φ1800	3.5	2.5	400	11
φ2000	4	3	400	11
φ2300	5.7	4	400	15
φ2400	6	4.5	450	15
φ2800	9.5	6	450	18.5
φ3000	10.2	7	500	22
φ3200	12	8	550	30
φ3600	18	10	550	45
φ4000	22	13	550	45
φ4200	25	14	550	55
φ4600	30	16	550	75

Application Of ANFD

Agitated Nutsche Filter Dryers (ANFDs) find wide application across various industries due to their versatility and effectiveness in performing multiple operations in a single unit.

Pharmaceutical Industry

ANFDs are extensively used in the pharmaceutical industry for processes such as filtration, washing, drying, and solid-liquid separation. They are ideal for producing high-quality pharmaceutical products, including active pharmaceutical ingredients (APIs), intermediates, and final formulations.

Chemical Industry

ANFDs are widely employed in the chemical industry for processes involving solid-liquid separation, filtration, washing, and drying of chemicals and intermediates. They are suitable for handling hazardous or toxic materials and can be used for product recovery and purification.

Food and Beverage Industry

ANFDs are utilized in the food and beverage industry for processes like filtration, separation, and drying of food ingredients, extracts, and beverages. They help in obtaining high-purity products and efficient removal of liquid from solids.

ABOUT US

Wuxi Zhanghua Pharmaceutical Equipment Co.,Ltd was founded in 1976, committed to researching, developing and manufacturing reaction, crystallization, filtration, drying equipment. With the development of the leading technologies for more than 40 years, our engineering equipment is not only for the pharmaceutical industry, but also for fine chemicals, pesticides, new energy, new materials and other industries.

We customize the integrated solution of reaction, crystallization, filtration and drying equipment for clients.

Technical Optimized Structural Design for Equipment.

Fast and Effective Solution to Malfunctions of Equipment.

Highly Efficient and Precise On-site Construction Service.

Commitment to the Customized Deadline.

A Full Range of long-term on-site technical maintenance service.

Contact us

Zhanghua is a leading pharmaceutical equipment manufacturer, specializing in the design, production, and distribution of high-quality filtration and drying equipment. With years of experience in the industry, Zhanghua has developed a reputation for excellence in the production of filter dryer pharmaceutical equipment, which is widely used in the pharmaceutical industry.

Range Of Premium Products

They are all manufactured according to the strictest international standards. Our products have received favor from both domestic and foreign markets.
They are now widely exporting to 200 countries.

Zhanghua - High Quality Hastelloy Agitated Nutsche Filter Dryer For Pharmaceutical Industry

Agitated Nutsche Filter Dryer (ANFD) is a versatile equipment used in industries for multiple process steps like solid-liquid separation, agitation, washing, and drying. They combine the functionalities of agitation, filtration, and drying in a single vessel. ANFDs consist of a cylindrical vessel with a perforated plate or filter medium at the bottom, along with an agitator. The agitator promotes efficient mixing, separation, and filtration. The liquid passes through the filter medium, leaving behind a filter cake that can be further washed and dried. ANFDs offer advantages such as flexibility, controllability, efficiency, and ease of operation, making them widely used in chemical, pharmaceutical, and fine chemical manufacturing.

Zhanghua - Stainless Steel Agitated Nutsche Filter Reactor For Filtering Washing

The agitated nutsche filter (ANF) is a versatile filtration device widely used in industries for solid-liquid separation processes. It consists of a cylindrical vessel with a perforated plate or filter medium at the bottom and an agitator inside. The agitator helps in mixing and dispersing the slurry, facilitating effective filtration. During operation, the liquid is drained through the filter medium, leaving behind a filter cake. The anf can be further equipped with features like washing, drying, and cake discharge mechanisms. With its compact design, efficient filtration capabilities, and easy maintenance, the agitated nutsche filter plays a crucial role in various applications, including the chemical, pharmaceutical, and food industries.

Zhanghua - Hastelloy Three In One Pharmaceutical Equipment Multifunctional Filter Dryer Agitated Nutsche Filter Dryer

Our R&D engineers applied the technology to the manufacturing of this kind of product.With those approved performances, the product can be widely found in the field(s) of Drying Equipment.
